Product Description
| Technical data | |
|---|---|
| Rotors diameter: | 40-120 mm (1,57-4,72 in) |
| Max rotor weight: | 3 kg (6,61 lb) |
| Stack lamination height: | 20-120 mm (0,79-4,72 in) |
| Max sensitivity: | 0.1 gmm/Kg (0,04 oz.in/lb) |
| Cycle time: (with 2 drilling on each plane) | 18 s |
| Controlled by: | Industrial PC |
| Balancing methods: | Axial drilling, angle drilling (30° to 60°) |
| Power supply: | 380-480 V three-phase 50/50 Hz |
| Machine dimensions (LxWxH): | 2500 x 2600 x 2200 mm (98,43 x 102,36 x 86,61 in) |
| Options |
|---|
| Reject conveyor |
| Industrial vacuum cleaner for removing drilling chips |
| Software SPC |
| Printer |
| Tele-service |
