Product Description
| Technical data | |
|---|---|
| Max rotor weight | 4 kg (8,82 lb) |
| Rotor diameter: | 20-80 mm (0,79-3,15 in) |
| Stack lamination height: | 20-80 mm (0,79-3,15 in) |
| Max production rate: | 140-180 pcs./hour |
| Controlled by: | Industrial PC |
| Measuring precision: | 0.1 gmm/kg max (0,04 oz.in/lb) |
| Balancing method: | Radial drilling or axial milling |
| Power supply: | 380-480 V three-phase 50/60 Hz |
| Machine dimensions (LxWxH): | 1500 x 1700 x 2200 mm (59,06 x 66,93 x 86,61 in) |
| Options |
|---|
| Re-checking unit |
| Industrial Vacuum cleaner for drilling chips |
| SPC/SW and printer |
| Printer |
| Teleservice |
| Marking device |
