Product Description
Range of balancing heads
Balance Systems’ SD balancing heads are the first devices in the world which have been specifically designed by Balance Systems with moment-free architecture. This solution brings the benefit of no dynamic-influence on the grinding spindle which improves the surface finishing.
SDE model is mounted externally by a flange and it is controlled via cable. This solution is suitable for retrofitting applications.
| Fitting diameter [mm] | Max compensation capacity [gcm] |
| 95 | 1700 |
| 114 | 6500 |
| 130 | 12000 |
SDI model is mounted inside the spindle shaft through a flange or a self-lock system and it is controlled via cable.
| Diameter of the spindle bore [mm] | Max compensation capacity [gcm] |
| 38 | 580 |
| 42 | 1200 |
| 50 | 2000 |
| 55 | 4400 |
| 60 | 5000 |
| 63 | 8700 |
| 70 | 8700 |
| 81 | 8700 |
