Product Description
| Technical data | |
|---|---|
| Max rotor weight: (with fiber support) | 0.5 kg (1,10 lb) |
| Max rotor weight: (with bearing support) | 5.5 kg (12,13 lb) |
| Journal diameter: | 2-40 mm (0,08-1,57 in) |
| Max rotor diameter: | 120 mm (4,72 in) |
| Range of belt dragging diameter: | 4-60 mm (0,16-2,36 in) |
| Min distance between support: | 20 mm (0,79 in) |
| Max distance between support: | 250 mm (9,84 in) |
| Balancing speed: | 200-2800 rpm |
| Min achievable residual unbalance: | 0.01 gmm (0,0089 oz/in) |
| Power supply voltage: | 110-230 V |
| Power requirement: | 0.3 kW |
| Machine dimensions (LxWxH): | 950 x 700 x 1300 mm (37,40 x 27,56 x 51,18 in) |
